Title

Puzzle Levers System

Author

Mister_Leebo

Submitted / Updated

07-15-2005 / 11-22-2006

Category

Games

Expansions

Works on all versions

View Code

// Include File for PLS System
// By Mister_Leebo

// CONSTANTS
const int PUZZLE_TYPE_SEQUENCE = 1;
const int PUZZLE_TYPE_BINARY   = 2;
// Made a different function to keep variables down
//const int PUZZLE_TYPE_TIMED    = 3;

const string LC = "LEVER_COUNT";
const string LG = "LEVER_GOAL";

// Set this to 1 to get informative messages about what's going on.
const int DEBUG = 0;



// Checks to see if the Sequence is finished
// For Binary, this returns TRUE only if no
// levers are toggled (the local bit mask is 0).
// Basically you can check to see if no doors are
// open this way.
int IsSequenceComplete(int iPuzzleType=PUZZLE_TYPE_SEQUENCE, string sID="", object oObject=OBJECT_SELF, int iCount=0);

// On Used for a Lever to run against the sequence.
// iPuzzleType : PUZZLE_TYPE_* (SEQUENCE|BINARY)
//  Binary = Switches act as toggles for multiple doors.
//  Sequence = You must activate all switches in the right order to open one door.
// sID : If you are going to have more then one maze in one area, you'll need
//  a unique sID to differentiate them.
// sFailScript : Use this to execute a script (OBJECT_SELF is oObject) that happens
//  if the sequence fails. This does nothing in Binary Puzzles because there is
//  no way to fail these puzzles.
// oObject : The object, usually the lever being used.
// bSoundHint : TRUE|FALSE
//  If TRUE, an audio cue is played if the PC is on the right track. NOTE: Sequence
//  puzzles without this clue will be EXTREMELY hard if no clues are provided in
//  other ways. This does nothing in Binary Puzzles as there can be multiple
//  'correct' solutions.
void RunLeverToggle(int iPuzzleType=PUZZLE_TYPE_SEQUENCE, string sID="", string sFailScript="", object oLever=OBJECT_SELF, int bSoundHint=TRUE );

// Opens and closes doors based on the sequence
void RunDoorToggle(int iPuzzleType=PUZZLE_TYPE_SEQUENCE, string sID="", object oObject=OBJECT_SELF);

// On Used for a Lever that activates a door that is open for only a short time
//  after the lever is pulled.
// fDelay : How much time in seconds passes before the door closes after opening.
// sID : If you are going to have more then one maze in one area, you'll need
//  a unique sID to differentiate them.
// sFailScript : Use this to execute a script (OBJECT_SELF is oObject) that happens
//  when the timer runs out and the door closes again.
// oObject : The object, usually the lever being used.
// bSoundHint : TRUE|FALSE
//  If TRUE, an audio cue is played as the door closes to let the PC know that
//  time is up.
void RunLeverTimer( float fDelay, string sID="", string sFailScript="", object oObject=OBJECT_SELF, int bSoundHint=TRUE );

// Randomly makes a new sequence for Sequence Door Puzzles, sets the sequence to
// 0 (all doors will close) for Binary puzzles. It is a good idea to reset
// a binary puzzle if players log out or die and respawn out of the puzzle so
// there's no chance of making it un-enterable.
void RunSequenceComplete(int iPuzzleType=PUZZLE_TYPE_SEQUENCE, string sID="", object oObject=OBJECT_SELF);

// Overwrites the default randomly generated sequence with a user sequence.
// Example: nSolution = 1234 or 333
void SetSequenceSolution( int nSolution, string sID="", object oObject=OBJECT_SELF );

// Only intended for SEQUENCE puzzles, used internally but public for use in
// sFailScript scripts.
int GetSequenceSolution( string sID="", object oObject=OBJECT_SELF );

Select All Text | View Code in separate window

Format

Module and Code

Type

Type - Puzzles

Includes

Custom

Description

Are you tired of the same old dungeons? Monsters, chests, and no variety? As a builder, do you want to make other forms of challenges but just don't have the scripting know-how to get it accomplished? Well, it's your lucky day!

The PLS scriptset adds three dynamic types of puzzles that involve levers and doors which can be combined to make a rich variety of puzzles to decorate your dungeons and castles with. The three types are:

Labrynth-like Mazes where pulling levers cause some doors to open but others to close.

Sequence-set Doors that only open if you can duplicate the Sequence using levers. The sequence can be randomly-generated to always keep the crowd guessing.

Time delay Doors that will keep your players on their toes!

Newbie-friendly tutorials make all of these mazes available to any class of builder and the system is open enough to allow other scripters to take their puzzles to new levels by coding in things like traps going off on failure, monster spawns, and more.

Files

Name	Type	Size	Downloads
PuzzleLeversSystem.zipPuzzleLeversSystem.zip Submitted: 07-15-2005 / Last Updated: 07-15-2005	zip	542.38Kb	847
The PLS System, includes an erf, two modules, and extensive tutorials/documentation.
